Bunting Bearings EP060808 3/8" Bore x 1/2" OD x 1/2" Length Powdered Metal SAE 841 Sleeve (Plain) Bearings Review
See more picture
Bunting Bearings EP060808 3/8" Bore x 1/2" OD x 1/2" Length Powdered Metal SAE 841 Sleeve (Plain) Bearings Feature
- SAE 841 bronze bearing for supporting radial and axial loads with a load-at-velocity value of 50,000 PV
- Sintered with powdered metals for strength, durability, and corrosion resistance
- Vacuum-infused with SAE 30 oil to provide lubricant from the bearing to the shaft during operation
- Operating temperature ranges from 10 degrees F to 220 F (-12 degrees C to 104 C)
- Straight bore fits conventional cylindrical shafts
This bronze Bunting Bearings powdered metal sleeve (plain) bearing is formed and sized to SAE (Society of Automotive Engineers) 841 specifications for supporting radial and axial loads. This bearing has been sintered with powdered metals for strength, durability, and corrosion resistance. It is vacuum-infused with SAE 30 oil, which remains in the pores of the bearing to provide lubricant from the bearing to the shaft during operation. This non-magnetic plain bearing has a maximum load value of 2,000 psi (pounds per square inch), a maximum velocity value of 1,200 sfpm (surface feet per minute), and a maximum load-at-velocity (PV) value of 50,000. It is designed to operate under temperatures ranging from 10 degrees F to 220 F (-12 degrees C to 104 C). Designed with a regular straight bore, this bearing fits to conventional cylindrical shafts. This oil-filled powdered metal sleeve (plain) bearing is for use in various applications such as heavy-lifting equipment, pumps, aircraft, and motors, among others.
Specifications
| Chemical and physical properties, and manufacture | AMS 4805 |
| Specification defining sampling procedures and tables for attribute inspection | ANSI/ASQC Z1.4 |
| Specifications for sintered, oil-infused bronze bearings | ASTM B438 |
| Specification for iron-base powder metallurgy (PM), oil-infused bearings | ASTM B439 |
| Metal Powder Industries Federation | CT-1000-K26 |
| Chemical and physical properties, and manufacture | ISO 9001 |
| Chemical and physical properties, and manufacture | MIL-B-5687D |
Plain bearings (with no rolling elements) are used to handle radial or axial loads by providing a low-friction motion between two surfaces as shafts rotate or move back and forth through the center of the bearing. The most common types are bushings (also called bush), with a sleeve or flanged design, and are measured by their bore (inside diameter), outside diameter, length, and width (thickness). Plain bearings are used in automobiles, construction equipment, medical applications, railroad cars, turbines, various military applications, aeronautics, space exploration, among others.
Bunting Bearings LLC manufactures a variety of bearings that meet standards for quality assurance established by the SAE, the American Society for Testing and Materials (ASTM), and the International Organization for Standardization (ISO), among others. Founded in 1907, Bunting Bearings LLC is based in Holland, Ohio.
